A-H AHCL630R CCL RECP 30A 250V 2P3W BL&BK L6-30R
167 Available for Delivery
Order by for Delivery
Usually available for pickup within 24 Hours
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Arrow Hart
Mfg Catalog # AHCL630R
Viking Electric Part # 341288
Color coded single receptacle. Rugged glass filled nylon body. Clearly marked rating, NEMA configuration and approval listings on receptacle face. One piece brass contacts offer superior performance and minimum heat rise. Back and side wiring terminal clamps for easy, secure wiring.

Categories

Overview

UPC 03266475841
Family Brand Name Eaton
Long Description Color coded single receptacle. Rugged glass filled nylon body. Clearly marked rating, NEMA configuration and approval listings on receptacle face. One piece brass contacts offer superior performance and minimum heat rise. Back and side wiring terminal clamps for easy, secure wiring.
Color Blue/Black
Type Color Coded, Ultra Grip
Material Glass Filled Nylon
Conductor Size 14-8 AWG
Applications For Industrial Use
Grade Industrial
Connection Type Back and Side Wired
Temperature Rating -40 to 70 C
Grounding Grounding
Contact Material 0.041 in T Brass
Dielectric Strength 2000 V
Blade Dimensions 1.62 in L x 1.12 in W x 3.64 in H
Environmental Conditions V0 Flammability Rated Per UL94
Number of Poles 2 Pole
Number of Wires 3
