Arrow Hart Wiring AH4100R9W 250 Volt 100 Amp 3-Pole 4-Wire Blue Receptacle
Product image thumbnail 0
Product image thumbnail 1
1 Available for Delivery
Order by for Delivery
Usually available for pickup within 24 Hours
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Arrow Hart
Mfg Catalog # AH4100R9W
Viking Electric Part # 21791

Specifications

  • Phase: Three-phase
  • Color: Blue
  • Face/Body Material: Nylon
  • Material: Nylon
  • Gender: Female
  • Allowable Wire Size: #4 -1/0 AWG, #12 - #16 AWG (pilot)
  • Amperage Rating: 100A
  • Number Of Poles: Three-pole
  • Contact Material: Nickel-plated brass
  • Back Box Style: AHBB100
  • Type: Receptacle
  • Horsepower: 10 hp
  • Design Type: Pin & Sleeve Receptacle
  • Environmental Resistance: IP67, IP69K
  • Number Of Wires: Four-wire, grounding
  • Voltage Rating: 250V
  • Application: Industrial;Food and Beverage;Wastewater Treatment

General

  • UPC: 032664732157
  • Product Length/Depth: 7.375 IN
  • Product Height: 6.25 IN
  • Product Width: 7.375 IN
  • Product Weight: 2.867 LB
  • Warranty: Refer to warranty document.
  • Certifications: Contact Manufacturer

Categories

Overview

UPC 03266473215
Long Description RECEPTACLE PIN AND SLEEVE 100 AMP 250 VOLT 3 PHASE 3 POLE 4 WIRE WT BLUE
GTiN 00326647321576
Length 7.375 in
Size 7.375 x 7.375 x 6.25
Color Blue
Voltage 250 Volt
Type Receptacle
Material Nylon
Applications IEC 309 Products
Mounting Type Receptacle
Height 6.25 in
Weight 2.867 lb
Standard UL
Connection Type Plug
Horsepower 10 hp
Temperature Rating 86 degrees F
Family Brand Name Arrow Hart Wiring
Insulation Material Nylon
Number of Phases 3
Tc Connection Pin & Sleeve
Actuator Lever
Amperage 100 Amp
Environmental Conditions See Spec Sheet
Number of Poles 3 Pole
Number of Wires 4
Sub Brand ArrowHart Series
