Arrow Hart Wiring AH1224GY 20 Amp 120/277 VAC 4-Way Gray Toggle Switch
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
Product image thumbnail 3
2 Available for Delivery
Order by for Delivery
Usually available for pickup within 24 Hours
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Arrow Hart
Mfg Catalog # AH1224GY
Viking Electric Part # 21740

Specifications

  • Allowable Wire Size: #14-10 AWG
  • Application: Industrial
  • Mounting Type: Wall
  • Voltage Rating: 120/277V
  • Wiring Method: Back and side
  • Connector Type: Screw
  • Color: Gray
  • Switch Type: Four-way
  • Terminal Enclosure Material T: Brass
  • Terminals: 0.031 in
  • Material: Polycarbonate
  • Height: 4.19 IN
  • Length: 1.3 IN
  • Width: 1.005 IN

Certifications

  • cULus Listed

Product Compliance

  • NAFTA

Overview

UPC 03266473489
Long Description Eaton Arrow Hart industrial grade toggle switch, #14-10 AWG, 20A, Industrial, Wall, 120/277V, Back and side, Screw, Gray, Four-way, Brass, Terminals: 0.031 in, Polycarbonate
GTiN 00032664734892
Length 1.3 in
Width 1.005 in
Color Gray
Operating Temperature -20 to 60 C
Voltage 120/277 Volt
Type 4-Way
Material Polycarbonate
Terminal Type 0.031 In
Connector Type Screw
Applications NON-RESI SWITCHES
Mounting Type Wall
Height 4.19 in
Wire Size 14-10 AWG
Connection Type Screw
Switch Type Four-way
Family Brand Name Eaton
Actuator Toggle
Contact Configuration Switches
Amperage 20 Amp
Wiring Method Back,Side
Enclosure Material Brass
Sub Brand Eaton Wiring Devices
