Arrow Hart Wiring 5661B 15 Amp 250 VAC 2-Pole 3-Wire NEMA 6-15R Brown Straight Blade Single Receptacle
Product image thumbnail 0
Product image thumbnail 1
7 Available for Delivery
Order by for Delivery
Usually available for pickup within 24 Hours
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Arrow Hart
Mfg Catalog # 5661B
Viking Electric Part # 11903

Specifications

  • Height: 4.19 IN
  • Length: 1.3 IN
  • Width: .87 IN
  • Allowable Wire Size: #14 to 10 AWG
  • Amperage Rating: 15A
  • Mounting Type: Flush
  • Voltage Rating: 250V
  • Wiring Method: Back and side
  • Color: Brown
  • Contact Material: Brass
  • Design Type: Receptacle
  • Nema Configuration: 6-15R
  • Number Of Poles: Two-pole
  • Number Of Wires: Three-wire
  • Receptacle Type: Two-pole, three-wire, grounding
  • Style Type: Single
  • Connection Type: Screw
  • Material: Nylon

Overview

UPC 03266438290
Long Description Eaton Arrow Hart extra heavy-duty industrial specification grade single receptacle,#14-10 AWG,15A,Industrial,Flush,250V,Back and side,Brown,Brass,Impact-resistant nylon face,Glass-filled nylon base,6-15R,Single,Screw,Nylon,Core pack
GTiN 00032664382901
Length 1.3 in
Width .87 in
Color Brown
Voltage 250 Volt
Type Straight Blade
Material Nylon
Applications INDUSTRIAL RECEPTACLES
Height 4.19 in
Family Brand Name Eaton
Amperage 15 Amp
Number of Poles 2 Pole
Number of Wires 3
Sub Brand Arrow Hart
Conductor Size 14-10 AWG
Grade Industrial
Wire Type Back Wire
Temperature Rating -20 to 60 C
Grounding Grounding
Contact Material Brass
Dielectric Strength 2000 V
Environmental Conditions UL 94 Requirements, V2 Rated Flammability
