Arrow Hart Wiring 4750 15 Amp 277 VAC 2-Pole 3-Wire NEMA L7-15 Black Locking Duplex Receptacle
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
Product image thumbnail 3
10 Available for Delivery
Order by for Delivery
Usually available for pickup within 24 Hours
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Arrow Hart
Mfg Catalog # 4750
Viking Electric Part # 9532

Specifications

  • Special Features: Corrosion resistant locking connector
  • Color: Black
  • Face/Body Material: Glass filled Nylon
  • Wiring Method: Back and side
  • Material: Glass-filled Nylon
  • Allowable Wire Size: #14-10 AWG
  • Amperage Rating: 15A
  • Number Of Poles: Two-pole
  • Contact Material: Brass
  • Type: Locking receptacle
  • Device Grade: Extra heavy duty industrial specification grade
  • Nema Configuration: L7-15
  • Design Type: Duplex
  • Number Of Wires: Three-wire, grounding
  • Receptacle Type: Locking
  • Operating Temperature: -40°C to 115°C (-40°F to 239°F)
  • Voltage Rating: 277 V
  • Application: Industrial

General

  • UPC: 032664433009
  • Product Length/Depth: 1.1 IN
  • Product Height: 6.5 IN
  • Product Width: 3.5 IN
  • Product Weight: .25 LB
  • Compliances: Federal Specifications Classification W-C375
  • Certifications: UL Listed

Overview

UPC 03266443300
Long Description Recp Duplex 15A 277V 2P3W H/L BK 4433009
GTiN 00032664433009
Length 1.38 in
Width 1.52 in
Color Black
Voltage 277 Volt
Type Locking Receptacle
Material Glass-filled Nylon
Applications LOCKING DEVICES
Height 1.83 in
Family Brand Name Eaton
Amperage 15 Amp
Number of Poles 2 Pole
Number of Wires 3
Sub Brand Eaton Wiring
Operating Temperature -40 To 115 C
Weight .25 lb
Wire Size 14-10 AWG
Connection Type Screw
NEMA L7-15
