Arrow Hart Wiring 1995GY 20 Amp 120/277 VAC 1-Pole Gray Momentary Toggle Switch
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
Product image thumbnail 3
1 Available for Delivery
Order by for Delivery
Usually available for pickup within 24 Hours
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Arrow Hart
Mfg Catalog # 1995GY
Viking Electric Part # 3525

Specifications

  • Special Features: Momentary toggle
  • Connector Type: Screw
  • Switch Type: Single-pole
  • Load Type: Motor Control, Fan, LED, Incandescent, ELV, MLV, CFL, Flourescent, Halogen
  • Terminal Enclosure Material T: Brass
  • Mounting Type: Flush
  • Color: Gray
  • Wiring Method: Side
  • Material: Polycarbonate
  • Allowable Wire Size: #14 to 10 AWG
  • Amperage Rating: 20A
  • Number Of Poles: Single-pole
  • Voltage Rating: 120/277 V
  • Application: Industrial

General

  • UPC: 040893642802
  • Product Length/Depth: 1.31 IN
  • Product Height: 3.28 IN
  • Product Width: 1 IN
  • Product Weight: .25 LB
  • Warranty: Refer to warranty document.
  • Certifications: CSA Certified

Overview

UPC 04089364280
Long Description Eaton Arrow Hart industrial grade toggle switch, Momentary toggle, #14-10 AWG, 20A, Flush, 120/277V, Back and side, Screw, Gray,Load type: Motor Control, Fan, LED, Incandescent, ELV, MLV, CFL, Flourescent, Halogen, 1P, Brass, Polycarbonate
GTiN 00040893642802
Length 1.31 in
Width 1 in
Color Gray
Operating Temperature -40 to 65 C
Voltage 120/277 Volt
Type 3 Position
Material Polycarbonate
Connector Type Screw
Applications INDUSTRIAL SWITCHES
Mounting Type Wall
Height 3.28 in
Weight .25 lb
Wire Size 14-10 AWG
Connection Type Screw
Family Brand Name Eaton
Actuator Toggle
Contact Configuration Momentary
Amperage 20 Amp
Wiring Method Back,Side
Enclosure Material Brass
Number of Poles 1 Pole
Load Type Halogen,ELV,MLV,CFL,Motor Control,Incandescent,Flourescent,LED,Fan
Sub Brand Eaton Wiring Devices
