3M MNG14-8FX 100/Bottle Nylon Insulated Ring
Product image thumbnail 0
Product image thumbnail 1
200 Available for Delivery
Order by for Delivery
Usually available for pickup within 24 Hours
Adding...
Order in multiples of 100 (pack qty) Already a Customer? Log in to view your pricing
Manufacturer 3M
Mfg Catalog # MNG14-8FX
Viking Electric Part # 43890

Features

  • Blue nylon-insulated, butted-seam barrel ensures a secure fit and offers reliable performance
  • Funnel-designed, seamless brass sleeve offers easy insertion of wires
  • 3M™ Scotchlok™ Color-Coded Standard Fork is a lug connection terminal that has a wider tongue for use on free-standing studs. The terminal has a nylon-insulated, butted-seam barrel and withstands temperatures of -40 to 221 degrees F (-40 to 105 degrees C). Electrolytic copper construction offers good conductivity and a tin-plated finish resists corrosion.
  • Wider-tongue design for use on free-standing studs
  • 3M™ Scotchlok™ Standard Fork Terminal is color-coded for quick and easy identification of the wire size required. It has a butted-seam barrel that is covered by a funnel-designed, seamless brass sleeve to guide the wire into position while providing electrical contacts and mechanical stress relief at the point of insulation. The abrasion-resistant, flared, nylon-sleeve insulation ensures positive grip and has a stepped design for mistake-proof crimping. UL Listed, CSA Certified and RoHS 2011/65/EU Compliant.
  • Stud size #8
  • Accommodates wire sizes 16 to 14 AWG
  • Electrolytic copper construction offers good conductivity
  • Withstands a temperature range of -40 to 221 degrees F (-40 to 105 degrees C)
  • 600V-rated for building wire and 1000V for signs, fixtures or luminaires
  • UL Listed, CSA Certified and RoHS 2011/65/EU Compliant
  • 100/carton, 500/case

Legal Disclaimer

  • The designation that a product is Manufactured in the USA means the product undergoes substantial transformation in one of our U.S. Manufacturing plants. Some products contain imported components.
  • Note: 3M products offered on a government contract that require country of origin representation must be certified by 3M Trade Compliance. Contact customer service at 800-245-3573 to request a certificate.

Specifications

  • 3M ID: 80611458110
  • Manufacturing Origin: USA
  • Brand: Scotchlok™
  • Color Family: Blue
  • Fork Type: Standard
  • Insulation Material: Nylon
  • National Stock Number: 5940008649542
  • Overall Length (Imperial): 0.91 in
  • Overall Length (Metric): 23.114 mm
  • Overall Width (Imperial): 0.34 in
  • Overall Width (Metric): 8.636 mm
  • Product Color: Blue
  • Stud Diameter (Imperial): 0.164 in
  • Stud Diameter (Metric): 4.166 mm

Overview

UPC 05112858666
Long Description Fork Nylon Insulated, 100/bottle, MNG14-8FX
GTiN 00051128586662
Type Fork
Material Nylon
Family Brand Name Scotchlok
Terminal Size 16 - 14 AWG
Sub Brand Scotchlok
Length 0.91 in
Width 0.34 in
Thickness 0.03 in
Barrel Type Butted
Stud Size 8
Terminal Style Standard
Terminal Type Fork
Conductor Size 16 To 14 AWG
Insulation Material Nylon With Insulation Grip
Color Blue
Overall Length 0.91 in
