3M CT4NT18-C 100/Bag 4 Inch Natural 18 lb Cable Tie
6,900 Available for Delivery
Order by for Delivery
Usually available for pickup within 24 Hours
Adding...
Order in multiples of 100 (pack qty) Already a Customer? Log in to view your pricing
Manufacturer 3M
Mfg Catalog # CT4NT18-C
Viking Electric Part # 28695

Overview

3M™ Cable Ties are made with high quality 6/6 nylon and designed to secure wire bundles and harness components quickly, without slipping. The 3M™ Cable Tie CT4NT18-C is 4.1" in length. Natural. 18 lb tensile strength. 100 pcs/bag.

  • Plenum Rated
  • Self Locking Head
  • Curved tip allows for faster threading and installation

Specifications

  • 3M ID: 80611469349
  • Agency Approvals: UL, UL Listed 62275 Type 21
  • Approximate Length: 4
  • Brand: 3M™
  • Cable Length: 4 Inch
  • Cable Length (metric): 104.14 mm
  • Cable Management Products: Cable Ties
  • Cable Tie Length: 101.6 mm
  • Color: Natural
  • Flammability Rating: UL 94 V-2
  • Length: 4.1 Inch
  • Length (Metric): 104 mm
  • Material: Nylon 6/6
  • Maximum Bundle Diameter: 0.75 Inch
  • Maximum Bundle Diameter (metric): 19.1 mm
  • Maximum Operating Temperature: 85 Degree Celsius
  • Maximum Operating Temperature (Celsius): 85 Degree Celsius
  • Maximum Operating Temperature (Fahrenheit): 185 Degree Fahrenheit
  • Maximum Recommended Voltage Rating: 600 V
  • Mil Spec: MS3367-4-9
  • Minimum Bundle Diameter (metric): 1.6 mm
  • Minimum Installation Temperature (Celsius): 0 Degree Celsius
  • Minimum Installation Temperature (Fahrenheit): 32 Degree Fahrenheit
  • Operating Temperature (Celsius): 85 Degree Celsius
  • Operating Temperature (Fahrenheit): 185 Degree Fahrenheit
  • Operating Temperature Range (Celsius): -40 °C to 85 °C
  • Operating Temperature Range (Fahrenheit): -40 °F to 185 °F
  • Plenum Rated: RoHS 2011/65/EU Compliant, Yes
  • RoHS 2011/65/EU Compliant: RoHS 2011/65/EU Compliant, Yes
  • RoHS EU Comments: RoHS 2011/65/EU compliant without exemption
  • Solution for: Long-haul/Metro Loop Network: CO/POP, Long-haul/Metro Loop Network: Outdoor, Wireless Network: Backhaul, Wireless Network: Infrastructure Accessories
  • Tensile Strength: Miniature (18 lb)
  • Tensile Strength (metric): 8.165 kg
  • Thickness: 0.035 Inch
  • Thickness (Metric): 1 mm
  • Trademark: 3M
  • Type: Standard
  • Units per bag: 100
  • UV Resistant: No, UV Resistant
  • Width: 0.1 Inch
  • Width (Metric): 2.5 mm

Legal Disclaimer

  • Manufacturing Origin: USA
  • The designation that a product is Manufactured in the USA means the product undergoes substantial transformation in one of our U.S. Manufacturing plants. Some products contain imported components.
  • Note: 3M products offered on a government contract that require country of origin representation must be certified by 3M Trade Compliance. Contact customer service at 800-245-3573 to request a certificate.

Overview

UPC 05112859275
Long Description Plenum RatedSelf-locking headCurved tip allows for faster threading and installation
GTiN 00051128592755
Length 4 in
Width 0.1 in
Color Natural
Type Miniature
Thickness 0.035 in
Material Polyamide
Applications For General use
Temperature Rating -40 to 85 C
Family Brand Name 3M
Max Operating Temperature 185 degrees F
Cable Length 4 in
Standard Packaging Qty 100/Bag
Environmental Conditions UL 94 Requirements, V2 Rated Flammability
Tensile Strength 18 lb
Bundle Diameter 3/4 in
